AESSE 2200

AESSE 2200

AESSE 2200 is a soundproofing mat made up of a very flexible bituminous membrane (1,1 mm thickness) coupled with a bonded polyester fibre layer (30/50 kg/ m3 density, 5 mm thickness). The production technique during the coupling phase gives to AESSE 2200 excellent characteristics of mechanical resistance, it is walkable, waterproof and has good absorption capacity to impacts. AESSE 2200 is used as an impact sound noise separating product between the screed and the lightweight screed for fixtures levelling. Easy to use, AESSE 2200 has an adhesive overlapping lateral selvedge so to avoid that during laying the imperfections can compromise, even slightly, the final result. The bituminous membrane allows the application whenever the use of self-levelling screeds is planned.

Product variants

Namerigidità dinamica assoluta s’Resonance frequency f0∆Lwconduttività termica λdef. alla compressione (dL-dB)Technical Sheet Data
Aesse 2200 ALU
AESSE 2200 SPP

MN/m3: •10∆ ¬ UNI EN 29052-1 ¬ Cert. n° 095-09-acu DS

Hz: •36∆ ¬ UNI EN 29052-1 ¬ Cert. n° 095-09-acu DS

dB: •34∆ ¬ UNI EN 12354-2 ¬ peso massetto soprastante 115 kg/m2

W/mK: •0,0431∆ ¬ UNI EN 12667 ¬ Cert. n° 035-09 the TR

mm: •1,9∆ ¬ UNI EN 12431 ¬ Cert. n°1190.11UN0050/12

Description

USE

AESSE 2200 is used as decupling elastic-resilient mat for the creation of floating floors to reduce the impact sound noises in buildings with any intended purpose, so to comply with the law requirements.

APPLICATION

It is efficiently used in any kind of floors, over the lightened screed.

NOTE

Absolute dynamic rigidity s’

Additional information

rigidità dinamica assoluta s’
Resonance frequency f0
∆Lw
conduttività termica λ
def. alla compressione (dL-dB)

Downloads

Technical sheet

Certificato
